Hot Sale K Spline Shaft Totally Enclosed DC Gear Motor 12V 3nm Torque Electric DC Motor For Golf Cart

100 Pieces
MOQ
$20.00(100 - 499 Pieces) $16.00(500 - 2999 Pieces) $14.00(>=3000 Pieces)
Price
Hot Sale K Spline Shaft Totally Enclosed DC Gear Motor 12V 3nm Torque Electric DC Motor For Golf Cart
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 3months-1year
Model Number: D49D1-2440-500
Usage: Home Appliance, SMART HOME, Golf Cart
Type: GEAR MOTOR
Torque: 3n.m
Construction: Permanent Magnet
Commutation: Brush
Protect Feature: Totally Enclosed
Speed(RPM): 500RPM
Continuous Current(A): 1.2A
Efficiency: IE 2
Motor Diameter: 49mm
Motor Type: Motor For Golf Cart
Voltage: DC12V 24V 36V 48V 72V
Power: 10W - 60W
Speed: 15 RPM - 500 RPM
Material Of Gear: Plastic / Copper Gear
Motor Gearbox: Worm Gearbox
Diameter Of Output Shaft: 6mm 8mm 10mm 12mm 14mm(optional)
Speed Sensor: Hall Sensor,encoder,opto Sensor
OEM / ODM Service: Accept
Basic Infomation
Model Number: D49D1-2440-500
Payment & Shipping Terms
Packaging Details: 10pcs/ctn motor for golf cart
Supply Ability: 2000 Piece/Pieces per Day motor for golf cart
Product Description
Hot Sell K Spline Shaft Dc Gear Motor 12 V 3nm Torque Electric Dc Motor for Golf Cart
NOTE:
1.Please inform the application of your brushed dc gear motors.
2.Please provide the load speed and load torque.
3.Please choose the mounting distance 50.80mm or 72mm.
Product Overview
Gear motor Specifications
Motor Dimension
45mm 49mm 59mm 63mm 76mm 88mm 110mm
Motor Power
DC 12V 24V 36V 48V 72V 110V
Material of Gear
Plastic gear / copper gear
Motor type
motor for golf cart
Motor Gearbox
Worm gear box
Diameter of Output Shaft
6mm 8mm 10mm 12mm 14mm(Optional)
Speed Sensor
Hall Sensor,Dc Motor with Encoder,Opto sensor,Brake motor
Factory Address
Huadu,Guangzhou
Our Dc Motors Advantage
1.Low noise < 60db
2.Long life span > 4000hr(continuously working)
3.Self Locking Motor, Forward & Reverse
4.Competitive factory price
5.Sample order are welcome
These are standard shafts of our company above. The diameter of the output shaft can be 6mm, 8mm, 10mm, 12mm, 14mm and so on.We can design and manufacture the shafts according to your demand.
Motor Usage
Worm gear motor applications:
shutter door motor ,intelligent clothes hanger motor,range hood motor ,lift table motor,tennis ball machine motor,motorized tv lift cabinet furniture motor,kitchen garbage disposal motor,mig wire feeder motor,Sewing Machine Motor,Vending Motor,Smart Home Intelligent Equipment,Office Intelligent equipment,Lifting Cabinet Motor,Electric Hospital Lift Bed Motor,Hydraulic Pump Motor ,Electric Forklift Motor,Motorized TV Rack Motor.
Details Images

1.Motor Plastic Gear

The plastic gear with low noise,low cost,long life within the torque range.

2.Copper Gear

The copper gear with high torque and high temperature resistance,and the life can belonger if the lubrication effect can be guranteed,So the cost higher thanplastic gear .

3.Electronic Rotor

Pure copper coil configuration,reducing resistance and high conductivity to ensure motor efficienty,stable and safe operation.

4.Magnet

Thickened magnets,strengthen the magnetic filed,high torque and strong anti-interference.

7.Hall Sensor

The sensor could record the speed if gear motor dc has encoder.

8.Brake

If the gear dc motor has brake,it could still rotate when the brake stops.
Recommend Products
D63L/R Series Motor
Motor Power:
30W,45W 80W,100W,120W(Max)
No-load Speed:
35 RPM,65 RPM,130 RPM,150 RPM,180 RPM,
210 RPM,270 RPM,300 RPM(Max)

High Torque Geared Dc Motor:
10N.m - 15N.m

Steel Sheel Length:
74-80mm
Gear Modulus:
75:1 60:1 60:2 60:4
Gear Ratio:
75:1 M=0.8
60:1 60:2 60:4 M=1

D49R/L Series Motor

Motor Power:
10W,15W,20W,25W,30W,40W,50W (Max)
No-load Speed:
15 RPM,35 RPM,70 RPM,100 RPM,150 RPM,180 RPM,200 RPM,300 RPM(Max)
Torque:5N.m - 8N.m
Steel Sheel Length:56-71mm
Gear Ratio:
70:1 56:1 56:2
Gear Madulus:
70:1 M=0.8
56:1 56:2 M=1

D59R/L Series

Motor Power:
20W,30W,40W,50W,60W,80W(Max)
No-load Speed:
15 RPM,30 RPM,60 RPM,80 RPM,130 RPM,150 RPM,180 RPM,210 RPM,250 RPM(Max)
Torque:6N.m - 10N.m
Steel Sheel Length:74-80mm
Gear Ratio:
70:1 56:1 56:2
Gear Modulus:
70:1 M=0.8
56:1 56:2 M=1

D76R/L Series

Motor Power:
45W,65W,80W,100W,140W,150W,180W,200W(Max)
No-load Speed:
25 RPM,40 RPM,60 RPM,90 RPM,120 RPM,150 RPM,180 RPM,220 RPM,300 RPM(Max)
Torque:12N.m-18N.m
Steel Sheel Length:
77-97mm
Gear Modulus:
75:1 60:1 60:2 60:4
Gear Ratio:
75:1 M=0.8
60:1 60:2 60:4 M=1

D88R(72) Series

Motor Power:
100W,120W,150W,200W,300W,500W,600W(Max)
No-load Speed:
20 RPM,100 RPM,180 RPM,200 RPM,220 RPM(Max)

Torque:23N.m - 30N.m
Steel Sheel Length:100mm
Gear Modulus:
82:1 64:1 53:1
Gear Ratio:
82:1 M=1
64:1 M=1.25
53:1 M=1.5

D88-D110 NMRV040 Gear Motor

Torque:50-100Nm

WEWIN could efficiently give solutions for meeting customers’requirements on different torques by adopting high quality brushed dc
motor with gearbox, which are customizable and providing corresponding encoders and brakes for choice.

Manufacturing Technique
Material Preparation
CNC Machining
Lathe
Milling
Scan the QR code and get the factory panorama
Hobbing

Hydraulic Press


Winding

Spot Welding

Gearbox
Die Casting Manal
Assembly QC
Life Tester
Torque Tester
Temp & Humi Chamber
Company Profile
Company Advantages:
1.Professional motor OEM & ODM manufacturer
2.20 years motor design experience 3.Experienced engineering designers
4.Fast delivery time,about 15-20 days if use our conventional output shaft
5.We have strict quality control system,each batch of goods will be tested for torque and noise before leaving the factory
Our main market:
Europe,America and Asia,including United Kingdom, Germany, Italy, France, Sweden, United State, India,Korea and so on.
Guangzhou Wewin Motor Co.,Ltd. is a professional company specialized in design and customization of small dc worm gear motor. The motor models mainly include D49 D59 D63 D76 D88 series, and all the motors can be installed with hall sensor, encoder, opto sensor and brake,so we accept OEM and ODM orders ,and manufacture the motor according to your required like voltage, power, speed, torque, dimension and motor direction.

Our boss is a doctor of dc gear motor with over 20 years experience in motor customization and production,we also has professional R & D team and testing centers to test gears and motors, and could guaranteed high quality products for customers,welcome to contact our customer service center.
Certifications
FAQ
Q1：Are you trading company or manufacturer ?
A1：We are manufacture Integration of industry and trade, with over 20 years experience in dc motor . Our company have accumulated skilled production line, complete management and powerful research support, which could match all of the customers' requirements and make them satisfied.
Q2：What is your main product?
A2：DC Motor: dc gear motor 24v and high speed motor without gearbox Welding equipment: Wire feeder for Mig Mag Welding Machine
Q3：What if I don't know which DC motor I need?
A3：Don't worry, Send your specification,and our team will help you find the right model you are looking for.
Q4：What is your payment term?
A4：Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T deposit in advance ,balance before shipment.
Q5：How to delivery?
A5： By sea - Ship out by buyer's appoint forwarder, or our sales team find suitable forwarder for buyers. By air - Ship out by buyer's express account, or our sales team find suitable express for buyers. (Mostly for sample) Others - Actually,samples send by DHL,UPS, TNT and Fedex etc. We arrange to delivery goods to some place from China appointed by buyers.
Q6：How long is your delivery time?
A6：Usually it takes about 35 days if buyer accept our standard output shaft.If the output shaft is customized,the production time depends on what the customization shaft it is.
