Totally Enclosed Robot Brushless Motor 48 24 Volt Dc Motor 1000W 2Kw 2000W 48V Bldc Permanent Magnet Brushless DC Motors

1 Piece
MOQ
Totally Enclosed Robot Brushless Motor 48 24 Volt Dc Motor 1000W 2Kw 2000W 48V Bldc Permanent Magnet Brushless DC Motors
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 1 Year
Model Number: D110BLD1000-24A-30S
Usage: BOAT, Car, Electric Bicycle, FAN, Home Appliance, Cosmetic Instrument, SMART HOME, Automatically Machine
Type: GEAR MOTOR
Torque: 3.18N.M
Construction: Permanent Magnet
Commutation: Brushless
Protect Feature: Totally Enclosed
Speed(RPM): 3000RPM
Continuous Current(A): 52.08A
Efficiency: IE 4
Direction Of Rotation: CW/CCW
Shaft Diameter: 19mm
Rated Power: 1000w
Rated Voltage: DC24V
Rated Speed: 3000 R/min
Rated Torque: 3.18n.m
Motor Diameter: 110mm
Weight: 5kg
Product Name: 1000w Brushless Dc Motor
No Load Speed: 3300r/min
Basic Infomation
Model Number: D110BLD1000-24A-30S
Payment & Shipping Terms
Packaging Details: According to the size of the motor for safe packing. 1pcs 48 24 volt dc motor 1000W 2kw 2000w 48v bldc permanent magnet brushless dc motor packed inside of carton
Supply Ability: 10000 Piece/Pieces per Month
Product Description
Kindly remind:
As different customers may need different motor parameter for fitting your equipment. If below motor can't fit your need, please kindly send inquiry to us with information for rated power or torque,rated speed, and rated voltage for our new size drawing making for you. Thanks a lot!
Dimensions (Unit: mm )
Mounting screws are included with gearhead
Model
D110BLD1000-24A-30S
D110BLD1000-36A-30S
D110BLD1000-48A-30S
D110BLD1000-310A-30S
Power W
1000
1000
1000
1000
Voltage V
24
36
48
310
No load speed rpm
4200
4200
4200
4200
Rated speed rpm
3000
3000
3000
3000
Rated current A
52.8
34.72
26.04
4.03
Rated torque N.m
3.18
3.18
3.18
3.18
Peak torque N.m
9.55
9.55
9.55
9.55
No-load current A
<12A
<8.5A
<6A
<1.2A
Customizable accessories:motor length, shaft, voltage,power,rated speed and so on.

Feature:
A. High power range from 5W to 20KW
B. Rich stock and fast shipping time in 10 working days
C. Easy for speed & direction adjustment
D. 16mm to 220mm size range with low noisy
E. Strong stability for driver/controller
F. Lifetime above continuous 10000 hours
G. IP65 protection rank is available for us
H. Above 90% enery efficiency motor is available
I. 3D file is available if customers needed
J. Permanent magnet brushless dc motor
K.High-performance and stable matching driver and controller

Notice for Usage:
1).Please don't use motor out of the range of nameplate of gear box and motor and the specification of product
catalogue, avoiding getting an electric shock, hurting or damaging the device.
2).Please do not put your fingers and things into
the opening part of gear or motor ,in order to prevent getting and electric shock,hurting,catching a fire of damaging device etc.
3).Please do not use the Injured gear head of motor, in prder to orevent hurting,catching a fire etc.
4).Please do not put off the
nameolate.
5) If the products are reformed by the customers personally, it no longer belongs to the guarantee scope, and our
company doesn’t undertake any responsibility.
6) When you move it, if it shed off or tilt to one side, it is very dangerous,
please pay more attention.
7) Please must not put the flammable thing near the gear head and motor, in order to prevent catching a
fire.
