| Number of poles | 4 |
| Number of phases | 3 |
| Rated speed RPM | 3000 |
| Product Keywords | Peak current Amps 42 BRUSHLESS DC PLANET GEAR MOTOR,Peak torque N-M 5.4 BRUSHLESS DC PLANET GEAR MOTOR,Output power W 565 BRUSHLESS DC PLANET GEAR MOTOR |
|
Housing Material |
Metal |
|
Bearing at output |
Ball Bearings |
|
Rated speed RPM
|
3000rpm |
|
Average life span |
20000 hours |
|
Ambient Temperature |
-20℃~+50℃ |
|
Model |
S86BL80-430 |
S86BL105-430 |
S86BL115-430 |
S86BL130-430 |
S86BL130-630 |
|
Number of poles |
4 |
||||
|
Number of phases |
3 |
||||
|
Nominal voltage VDC |
48 |
48 |
48 |
48 |
310 |
|
Rated speed RPM |
3000 |
3000 |
3000 |
3000 |
3000 |
|
Rated torque N-M |
1 |
1.8 |
2.1 |
2.5 |
2.5 |
|
Rated current Amps |
8.5 |
14.8 |
17 |
19.5 |
4 |
|
Output power W |
314 |
565 |
659 |
785 |
785 |
|
Peak torque N-M |
3 |
5.4 |
6.3 |
7.5 |
7.5 |
|
Peak current Amps |
25 |
42 |
51 |
55 |
12 |
|
Torque constant N-M/A |
0.131 |
0.131 |
0.127 |
0.127 |
0.127 |
|
Back EMF constant V/KRPM |
13.7 |
13.7 |
13.3 |
13.3 |
13.3 |
|
Rotor inertia Kg•mm² |
120 |
230 |
266 |
320 |
320 |
|
Body length mm |
80 |
105 |
115 |
130 |
130 |
|
Mass Kg |
2.3 |
3.4 |
3.8 |
4.3 |
4.3 |
